Pneumatic Lug Type Butterfly Valve

Automated pipeline isolation becomes more practical when a compact lug-style valve is paired with the required control arrangement. Our Pneumatic Lug Type Butterfly Valve is designed for industrial flow-control requirements with a 100 mm stated size, EPDM seating, cast iron body, and lug-type construction. Manufactured by Shiv Valves Industries in Ahmedabad, Gujarat, the range is intended for applications where repeatable valve operation and convenient automation are important.

Compact Lug Construction with Automated Control

A lug type butterfly valve is installed between compatible flanges, with the lug arrangement providing defined mounting points for pipeline installation. The quarter-turn butterfly mechanism allows the disc to move between open and closed positions, while the pneumatic actuation arrangement can support faster and more consistent operation than purely local manual handling.

The supplied specifications identify an automatic configuration, while the product information also mentions lever operation and electrical power options of 230V AC / 24V DC. These details should be matched to the exact actuator and control configuration required for the installation before ordering.

Product Specification Sheet

EPDM Seating for Specified Service Conditions

The valve incorporates an EPDM seat, providing the resilient sealing interface around the disc. Seat selection is an important consideration in any butterfly valve installation because compatibility depends on the process medium, temperature, pressure, and operating environment. The specified PN10 and PN16 ratings should likewise be considered according to the particular valve configuration and service conditions.

Range Built Around Multiple Pipeline Requirements

Although the stated valve size is 100 mm, the supplied product range covers 40 mm to 800 mm, providing options for different pipeline dimensions. The EN 558-1 face-to-face specification gives an established dimensional reference for compatible installation planning. The combination of lug-style mounting and automated operation makes the valve suitable for systems where remote or repeated flow isolation is required.

• Lug type butterfly valve construction.
• 100 mm stated valve size with a 40 mm to 800 mm range.
• Cast iron body and cast steel material specification.
• EPDM resilient seat.
• Automatic configuration for controlled operation.
• EN 558-1 face-to-face specification.
• 230V AC / 24V DC power options as specified.
• PN10 / PN16 pressure specifications depending on configuration.
• Made in India and available with minimum order quantity of 1 piece.

Industrial Valve Requirements from Ahmedabad

Established in 2022, Shiv Valves Industries serves industrial valve requirements from Ahmedabad, Gujarat, with an emphasis on defined product specifications and quality standards. The Pneumatic Lug Type Butterfly Valve can be evaluated according to pipeline size, pressure class, operating method, seat requirement, and automation arrangement.

To discuss your requirement for a Pneumatic Lug Type Butterfly Valve in Ahmedabad, Gujarat, share the required valve size, operating pressure, medium, actuator/control requirement, and quantity with Shiv Valves Industries for the appropriate configuration.
