Pneumatic Actuator Operated Butterfly Valve

Large-diameter flow lines need dependable actuation as much as they need a robust valve body. Our Pneumatic Actuator Operated Butterfly Valve is designed for automated quarter-turn flow isolation, combining a stainless steel valve construction with a double-acting pneumatic actuator. With sizes ranging from 50 mm to 1000 mm and a specified 12-inch configuration, this valve provides a versatile solution for industrial piping systems where pneumatic operation and compact wafer installation are required.

Automation That Brings Controlled Valve Movement

The valve uses a double-acting pneumatic actuator to operate the butterfly mechanism. An air supply of 4–6 bar is specified for actuation, while the solenoid valve provides pneumatic control. This arrangement can be integrated into automated process systems where remote or controlled opening and closing is preferred over conventional manual operation.

The SVI configuration can also be supplied with application-related accessories such as an air filter regulator, limit or proximity switch box, solenoid valve and positioner. These components can support pneumatic control, valve-status indication and process automation requirements depending on the selected configuration.

Detailed Technical Specifications

Stainless Steel Construction with PTFE Seating

The stainless steel body and material specification provide a sturdy construction for industrial valve installations. The PTFE seat is selected as the seating material for suitable compatible service conditions, while the wafer-end configuration helps maintain a compact installation arrangement between pipeline flanges. The combination is suitable for projects where installation space, pneumatic automation and defined pressure service are important design considerations.

Functional Highlights of the SVI Configuration

• Double-acting pneumatic actuator for controlled quarter-turn operation.
• 4–6 bar air supply requirement for the specified actuator arrangement.
• Stainless steel body and valve construction.
• PTFE seat material for compatible process applications.
• Wafer-end connection for a compact pipeline configuration.
• PN10 pressure rating for the specified operating class.
• Solenoid valve arrangement for pneumatic actuation control.
• Optional positioner and switching accessories for automation requirements.
• Available size range from 50 mm to 1000 mm, subject to configuration.

Designed Around Industrial Automation Requirements

This pneumatic butterfly valve is suitable for industrial flow-control systems where automated isolation is required. The broad stated size range allows the valve concept to be considered for both smaller process lines and large pipeline installations. The combination of pneumatic actuation, switch-box options and air-control accessories makes it adaptable to different levels of plant automation.

Shiv Valves Industries, established in 2022, manufactures the SVI range from Ahmedabad, Gujarat, with application-focused valve configurations. The pneumatic actuator operated butterfly valve can be evaluated according to pipeline size, pressure conditions, required accessories and operating requirements.

For technical specifications, pneumatic actuator configuration, accessory selection or supply requirements, contact Shiv Valves Industries in Ahmedabad, Gujarat for the appropriate Pneumatic Actuator Operated Butterfly Valve configuration.
