2/2 Way Angle Type On/Off Control Valve

Fast isolation becomes especially valuable when a process line has limited installation space and needs dependable automatic switching. The 2/2 Way Angle Type On/Off Control Valve from Shiv Valves Industries is designed around this requirement, combining an angle-body flow path with pneumatic actuation for rapid opening and closing. Its stainless steel construction, PTFE seat and Class VI leakage rating make the DN25 configuration suitable for a range of industrial media.

Angle-Body Design for Efficient On/Off Service

This valve uses a two-way, two-position arrangement in which the flow passage is either open or closed. The angle configuration can help provide a compact piping arrangement while offering a comparatively direct flow path. Pneumatic operation allows the valve to be integrated into automated systems where frequent and consistent switching is required.

The DN25 model features a 1-inch port, threaded end connection and single-port construction. Depending on the actuator configuration, angle-type pneumatic valves can be arranged for normally closed, normally open or double-acting operation. This makes the design adaptable to different control philosophies and process requirements.

Technical Details for Product Selection

Construction Details That Support Industrial Operation

• Stainless steel body: Provides a corrosion-resistant valve body suitable for demanding industrial environments.
• PTFE seat: Provides sealing around the specified operating conditions and supports compatibility with a broad range of media.
• Pneumatic actuation: Enables automated valve switching using compressed air.
• Threaded ends: Provide a convenient connection arrangement for compatible DN25 piping installations.
• Single-port configuration: Provides a straightforward two-way flow-control arrangement.
• Class VI leakage rating: Supports bubble-tight shutoff performance for the specified configuration.

Media Versatility Across Process Lines

The valve is specified for water, steam, chemical media, gas, oil and air. This broad media range makes the DN25 configuration relevant to utility lines, pneumatic systems, process equipment, fluid transfer arrangements and automated isolation points. Actual suitability should be evaluated against the specific media composition, pressure and temperature before installation.

Operating Characteristics and Available Configurations

Angle-type pneumatic valves are commonly selected where quick response, compact installation and repeated cycling are important. The supplied design information indicates operating pressure ranges of approximately 4.5–7 bar for smaller sizes, with higher-size configurations extending to 5–7 bar. PTFE sealing configurations can be used up to the specified temperature range of approximately 180°C, subject to the complete valve specification and service conditions.

Shiv Valves Industries, established in 2022, supplies industrial valve solutions from Ahmedabad, Gujarat, with attention to defined product specifications and application requirements. The 2/2 Way Angle Type On/Off Control Valve is available with a minimum order quantity of 1 piece.

For requirements of a DN25 2/2 Way Angle Type On/Off Control Valve in Ahmedabad, Gujarat, provide your media, operating pressure, temperature, connection and pneumatic control requirements to Shiv Valves Industries for suitable product configuration.
